Flat die granulator also called flat die pellet mill, it is a kind of pelletizing equipment used to press powdery raw materials into pellets, which is widely used in feed, fertilizer, biomass energy, chemical industry and other industries.
The equipment compresses the raw materials into high-density granules through the interaction of pressure roller and flat die, featuring high molding rate, uniform granules and low energy consumption.
Winwork offers a wide range of flat die granulators with MOQ of 1 and customized services.
Flat Die Granulator Process Principle
The crushed raw material enters into the pressing chamber through the funnel-shaped inlet above, and the pressure roller inside the pressing chamber keeps rotating and interacting with the flat die to squeeze the raw material into high-density pellets, the diameter and length of which can be controlled by the shape and size of the flat die holes.
After pressing, the pellets are extruded from the holes of the flat film, and then cut into the required length by the cutter below. The pellets after pelletizing have a smooth surface, uniform density and a pelletizing rate of over 95%.
Advantages of flat die granulator process
High efficiency and energy saving: the flat die pellet mill adopts advanced design of pressure roller and flat die, high pressing efficiency and low energy consumption.
Strong adaptability: it is suitable for a variety of raw materials, such as feed, fertilizer, biomass, etc., and different specifications of pellets can be produced by changing the mold.
High pellet quality: uniform pellet density, smooth surface, high molding rate, meet the quality requirements of different industries.
Environmental protection and no pollution: no dust and exhaust gas emission in the pressing process, in line with the requirements of environmental protection.
Easy to operate: the equipment has simple structure, favorable price, easy to operate and maintain, suitable for continuous production.
